Hybrid Plus, 1" Conn., 86Lpm, CMB 5-47 pump (0.9kW)

  • •Weather proof triple rainwater filter with UV

  • •86 LPM, 1" connection

  • •CMB-SP 5-47 pump (0.9kW)

Price: $9,267.57 INC GST*

Model No: HYBRID-P6-LF

WHERE TO BUY

REQUEST A QUOTE

Get quick pricing and expert advice from our support team.

Submit your inquiry today

The Puretec Hybrid-P6 is an all-in-one filtration system including pump, 3 stage filtration and finishing with UV sterilisation. This sleek, practical and high-quality system ensures you have pressurised safe and delicious rainwater.

The patented HybridPlus system is designed to sit neatly against a wall, fence or tank, or can also be freestanding. It features a lockable cabinet with gull-wing style access doors for ease of access for maintenance and also incorporates adjustable feet to ensure a neat and tidy finished installation.

Specifications

Model No
HYBRID-P6-LF
Replacement Cartridge(s)
Stage 1 filtration
PL05MP2
Stage 2 filtration
CB05MP2
Stage 3 filtration
PX01MP2
UV Lamp
RL6
Quartz Sleeve
RQS6
Grundfos pump model
CMB-SP 5-47
Rated power
0.9 kW
Pressure controller
PM2
Mains to rains controller
not included
Power Supply
220-240 VAC / 50 Hz
Maximum current consumption
5.4-5.0 A
Water temperature range
0-52°C (protect from freezing)
Self-priming
4 m
UV dosage @40mJ/cm2
54 Lpm
UV dosage @30mJ/cm2
70 Lpm
UV dosage @16mJ/cm2
130 Lpm
Pump flow rate
86 Lpm
Connection
1” BSP [25mm]
Warranty
3 years^
Important Note: Use only genuine Puretec replacement cartridge. Flow rate @30mJ/cm2 is the industry standard for drinking water. ^Warranties in this document cover parts for 3 years and include cover for parts and labour for the first year where applicable, subject to approval excluding the pump which is covered by Grundfos’s own back-to-base 2 year warranty.

Features & Benefits

  • •Designed specifically for rainwater, the Puretec HybridPlus is a complete plug & play package with pump, filters & UV in one unit that is weatherproof, rodent-proof, tamper proof and reduces pump noise.
  • •Bacteria protection - Kills 99.9% of E. Coli, Giardia and Cryptosporidium Cysts with Radfire ™ ultraviolet technology, natural process that’s completely eco-friendly and chemical-free.
  • •Unique connection system so that water flow can be connected to the left or right-hand sides for fast, easy and neat installation.
  • •Patented cabinet with gull-wing style access doors looks great whilst providing easy access for maintenance, is corrosion resistant and lockable to prevent tampering.
  • •Neatly concealed ventilation to allow airflow and heat dissipation.
  • •Suitable for other water supplies - depending on water quality (refer to Puretec Customer Care).

Download

General Downloads

For Specifiers

Videos

    Spare Parts

    Maintenance kit suits all Hybrid P series, G13 and R11

    Maintenance kit suits all Hybrid P series, G13 and R11

    $1,104.83 INC GST*

    Do you still have questions about this product?

    If you have any more questions, our team is very happy to assist. Please call 1300 140 140
